• Computer control, convenient and fast order adjustment.
• Belt type leading edge paper feeding system, adjustable air section, variable frequency control of air volume
• Computer control, convenient and fast order adjustment.
• Belt type leading edge paper feeding system, adjustable air section, variable frequency control of air volume
• Paper feeding without pressure feed structure, protecting cardboard from compressive loss.
• Adjustable gluing system with constant glue temperature ensures optimal adhesion characteristics.
• The mesh hole type pasting wheel system ensures stable gluing, regulates the amount of glue, and electrically regulates the position.
• The extended high-strength folding box bridge arm is supported by a high-strength bridge seat in the middle, ensuring smooth high-speed operation.
• The unique right angle forming wheel forming structure ensures the folding effect of the cardboard box.
• Adopting a precision linear guide rail synchronous lateral displacement system, the displacement is precise.
• Elastic guide gauge pressure wheel device, upper and lower belts for clamping and guiding.
• Unique folding correction wheel system, assisted by navigation aids, with excellent folding forming effect.
• The rear section is equipped with an adsorption type belt conveyor and independent motors on both sides to drive the correction device, effectively correcting the deviation.
• High frequency box straightening with "up falling type" and falling rolling belt.
• Paper receiving lifting support rod, blowing assistance, pneumatic flat pushing, and circulating collection.
• The "down stack type" high-speed counting and stacking loop transmission system has high production efficiency.
• Conveyor belt output, paper pressing roller track assistance, and pneumatic control of paper output gap.
• Counting output unit horizontal movement electric adjustment.
| Model | 920B | 924B | 1224B | 1228B |
| Folding minimum spacing | 350 | 350 | 350 | 350 |
| Min . Folding spacing | ||||
| Sheet side | Min 150 | Min 150 | Min 150 | Min 150 |
| Max 1000 | Max 1000 | Max 1000 | Max 1000 | |
| Sheet reverse side | Min 150 | Min150 | Min 150 | Min 150 |
| Max 1000 | Max 1000 | Max 1000 | Max 1000 | |
| Folding accuracy | ±1.5 | ±1.5 | ±1.5 | ±1.5 |
| Minimum paper feed height | 300 | 300 | 300 | |
| Min. Feeding height | 300 | |||
| Production speed | 280 | 250 | 230 | 200 |
| Speed |
The company has been rated as "high-tech enterprise", "Cangzhou enterprise technology center" and "National Science and technology small and medium-sized enterprises". The company has won the honors of "China Quality AAA brand enterprise", "China's key promotion brand of scientific and technological innovation", "trustworthy unit of consumers", "advanced export unit" and "enterprise abiding by contract and trustworthiness".
The company has established a sound quality management system and obtained iso9001:2015 international quality management system certification and EU CE certification.
QUALITY/QUANTITY DISCREPANCY AND CLAlM
1. ln case the quality and/ or quantity are found by the user to be not in conformity with the contract after arrival of the goods at the port of destination, the user may lodge claim with the seller supported by a survey report issued by an inspection organization agreed upon by both parties, with the exception, however, of those claims for which the insurance company and/or the shipping company are to be held responsible.
2. The claims should be filed by the user within 30 days after the arrival of the goods at the port of destination.
WARRANTIES
1. All the equipment supplied by the seller shall be of good quality, brand new and free of defect, in accordance with design and specification.
2. The warranty period is 1 year after sign the act of acceptance between the seller and user.
3. Duration Of Warranty:
Seller's obligation shall commence on the effective date and continue through the period ending 1 year after sign the act of acceptance. Within the indicated time seller shall make good or replace by his force and on his account defective/worm block, parts or any parts thereof, spare parts which do not allow to normally utilize the equipment and produce amounts intended. Replaced defective parts.
4. Installation Services:
After customer get all machines we will arrange engineers to oversea to install the machine (the specific installation time depends on the local conditions).
5. When there is a problem with the machine or the customer cannot operate the machine, we will immediately give the customer's solution and video to help the customer run the machine.
